Product Specifications – Moving Jet DMX Controller
Input Voltage: 9–24V DC (Wide Range Power Support)
Control Protocol: DMX 512 / Art-Net Compatible
Pulse Per Revolution: Configurable (Default: 2000) – Matches stepper motor driver settings
Maximum Speed: Up to 5000 pulses per second
Acceleration Control: Adjustable (Default: 2000) for smooth motion transitions
Position Offset: Configurable for precise alignment correction
Maximum Rotation Angle: Up to 180°
Noise Filtering: Adjustable noise threshold (Default: 20 ms) for stable sensor input
Motion & Direction Control
Selectable Rotation Direction: Clockwise / Anticlockwise
Independent Calibration Rotation Direction
Adjustable Offset Rotation Direction
Sensor & Input Configuration
Detection Sensor Input: NC (Normally Closed) / NO (Normally Open) selectable
Input Mode Selection: DMX or Wireless Art-Net

Channel
DMX Range
Function
CH1
0 – 255
Position Control
CH2
0 – 255
Acceleration Control
CH3
0 – 127
128 – 255
Motor Driver Disable
Motor Driver Enable (Energy Saving Mode)

Additional Features

High-precision control for 1D Moving Jet & Robotic Fountain Nozzles
Smooth and synchronized motion for musical fountain applications
Built-in live testing functionality for quick setup and diagnostics
Trusted Indian Quality
